We sell high-quality and affordable Facial Capture Machine in Chicago.
H.2,65.2 million face detection, capture, ultra-lowTE-FD52S7CA3-A2IR
Functional Characteristics
◆ The highest resolution is up to 2M (1920 X 1080 @ 25 fps);
◆ Support face detection, capture, to the weight and optimization;
◆ Support Smart IR to prevent infrared overexposure at night;
◆ H.265 Efficient compression, save bandwidth and storage space;
◆ Support low code rate, low latency, ROI region of interest enhanced coding;
◆ ICR infrared filter type automatic switch, to achieve the real day and night monitoring;
◆ Support the corridor mode, and increase the monitoring area under the longitudinal long and narrow environment;
◆ Support for PoE power supply function (optional);
◆ Expanded Micro SD card (128G) local storage;
◆ Support 3D digital noise reduction, digital width dynamic;
◆ Support for automatic electronic shutter function, to adapt to different monitoring environment;
◆ Support a variety of intelligent alarms;
◆ Support two-way voice intercom;
◆ Scalable support 1 alarm input / 2 alarm output;
◆ Support for Email and NTP services;
◆ Support for HTTPS encryption transmission;
◆ Start up the initial device to change the password to ensure the password security;
◆ Support for mobile phones (Android, Apple) remote monitoring.
Technical Parameter
| model | FD52S7C |
| imaging sensor | 1 / 2.8 ', 2 megapixel line scan ultra low illumination CMOS |
| Day and night conversion mode | ICR switch, automatic / color / black / white / external trigger |
| Wide Dynamic | WDR (Off / Low / Medium / High) |
| Light board control | Automatic / manual / off |
| 3D noise reduction | Closed / low / medium / high / high |
| Go to the fog | Off / low / medium / high |
| acoustic image | Close / horizontal mirror / vertical mirror / 180° rotation / 90° rotation / 270° rotation |
| Image Settings | Brightness, contrast, sharpness, saturation, chromatic |
| Face detection |
|
| Number of face tests | It can detect 30 individual face targets simultaneously |
| To detect the size of the face | Face pixels are 80 * 80 |
| shelter from | Ordinary glasses, shorter bangs had no effect on recognition |
| expression | Normally, a slight expression does not affect the recognition |
| Face detection rate | 99% (meet the above conditions) |
| Capture response speed | ≤1S |
| Maximum capture ability | 15 fps / s, with 30 faces per frame |
| Personnel tracking | support |
| Face quality filtering | support |
| surveyed area | Support the specified area, the default full screen |
| Shield area | 4 locsettings are supported |
| Upload method | Private Agreement Upload |
| Trigger way | Video trigger |
| Audio and video coding |
|
| Video coding criteria | H.265/H.264 / MJPEG (Substream) |
| Encoding features | Main code stream: 1920 * 1080 @ 25 fps; subcode stream: D 1 @ 25 fps; Third code stream: 1920 * 1080 @ 10 fps. |
| Video code rate | Fixed bit rate, variable code rate (16 kbps-8000 kbps) |
| Video type | Composite stream / video streaming |
| Audio coding standard | G.711u/64kbps |
| Region of interest (ROI) | Support 4 regions and can set multiple levels |
| Network function |
|
| networking protocol | TCP/IP,UDP,HTTP,DHCP,RTSP,DDNS,NTP,PPPOE,UPNP,SMTP |
| Interface protocol | ONVIF, T8S, GB28181 (optional) |
| Also preview the video | Five |
| safe mode | Authorized user name and password, HTTPS encryption, AES connection encryption, and RTSP authentication |
| Mobile detection | Set the check area, you can set the multilevel sensitivity |
| Cover the alarm | The 1 locale setting is supported |
| Privacy cover | Support for 4 area occlusion blocks |
| Event linkage | Capnap, TF card video, send Email, alarm output linkage, preset point linkage |
| Mobile phone monitoring | Support Apple, Android system mobile phone monitoring |
| Break the network to make up | Support, cooperate with NVR implementation |
| Equipment anomaly detection | Support the network cable break, IP conflict, illegal access to the alarm |
| Character Overlays (OSD) | Title, time and date overlay, multiple line OSD, OSD color optional |
| system upgrade | Support remote upgrade |
| joggle |
|
| network interface | RJ45 10M / 100M network adaptation |
| Analog video output | 1 route 1.0 Vp-p composite video output |
| audio frequency | Line input / line output |
| Alarm input | 1-way input (extension board) |
| Alarm output | 2-way output (extension board) |
| reset button | Support (extension board) |
| The RS485 interface | Support (extension board) |
| TF lay in | Support for up to 128G, Micro SD (SDHC / SDXC) card local storage (expansion board) |
| convention |
|
| source | The DC12V / POE is optional |
| Equipment size | 38*38mm |
| working temperature | -20℃~55℃ |
| Working humidity | 0%-90% |
Note: This parameter is for reference only, please take the physical object, subject to change without notice.
